Chapter 2 Functions of the Front Panel RIGOL
VNA User Guide 2-27
Table 2-21 Port 1 Length (m)
Parameter
Remarks
Default
0.00 m
Range
-3.00 Gm to 3.00 Gm
Unit
Meter (m, dm, cm)
Knob Step
Port 1 length/100
Left/Right Arrow Key Step
Up/Down Arrow Key Step
Port 1 length/50
Table 2-22 Port 1 Length (ft)
Parameter
Remarks
Default
0.00 m
Range
- 32291731348.30 ft to
32291731348.30 ft
Unit
ft
Knob Step
Port 1 length/100
Left/Right Arrow Key Step
Up/Down Arrow Key Step
Port 1 length/50
Port 1 Velocity Factor
Sets the velocity factor of Port 1.
Table 2-23 Port 1 Velocity Factor
Parameter
Remarks
Default
1
Range
0.1 to 1
Unit
N/A
Knob Step
0.1
Left/Right Arrow Key Step
Up/Down Arrow Key Step
at 1-2-5 step
Port 1 Specific Loss
Sets the cable loss for Port 1.
Table 2-24 Port 1 Cable Loss
Parameter
Remarks
Default
0.00 dB/m
Range
0.00 dB/m to 5.00 dB/m
Unit
dB/m
Knob Step
0.1 dB/m
Left/Right Arrow Key Step
Up/Down Arrow Key Step
at 1-2-5 step
