RIGOL Chapter 2 Functions of the Front Panel
2-28 VNA User Guide
Cal Kits
Before performing calibration, select one of the calibration kits.
If you select a customized kit, define it by yourself.
Selected Kit
The kits supported by VNA include:
⚫ CK106A
⚫ CK106E
⚫ Custom
By default, CK106A is selected.
Parts Type
The kit types supported by VNA include:
⚫ Open
⚫ Short
⚫ Match
⚫ Through
Parts Parameters
CK106A and CK106E are default kits. Their parameters are not recommended to be
modified.
The default parameters of CK106A are as follows:
Parts
Type
Offset
Length
Z
0
Att
Parameter
Open
14.89mm
50Ω
-
C0(fF)
C1(fF/GHz)
C2(fF/GHz
2
)
C3(fF/GHz
3
)
-
-2.71202
2.47817088
-0.19730637
-0.02094
Short
13.47mm
50Ω
-
L0(pH)
L1(pH/GHz)
L1(pH/GHz
2
)
L1(pH/GHz
3
)
-
-18.165068
28.77678
-8.6055475
0.6595
Match
0.00mm
50Ω
-
-
-
-
-
Through
0.0000mm
-
0.00dB
-
-
-
-
The default parameters of CK106E are as follows:
Parts
Type
Offset
Length
Z
0
Att
Parameter
Open
0.000mm
50Ω
-
C0(fF)
C1(fF/GHz)
C2(fF/GHz
2
)
C3(fF/GHz
3
)
-
0.000
0.000
0.000
0.000
Short
0.000mm
50Ω
-
L0(pH)
L1(pH/GHz)
L1(pH/GHz
2
)
L1(pH/GHz
3
)
-
0.000
0.000
0.000
0.000
Match
0.00mm
50Ω
-
-
-
-
-
Through
0.0000m
m
-
0.00dB
-
-
-
-
