Rigol RSA5065N-OCXO User Manual

Chapter 5 Shortcut Key RIGOL
RSA3000 User Guide 5-5
Reference Trace
Off
--
Mode
Measurement Mode
GPSA
Mode Setup
Global CF Mode
Off, 0 Hz
Off, 0 Hz
Meas
[2]
Measurement Function
Swept SA
Measurement
Normal
Measure Setup
[2]
（GPSA）
Swept SA Measurement
Avg Number
100
Avg Mode
Log
Avg State
On
Test Limits
Off
Select Limit
Limit1
Limit State
Off
Test Trace
Trace1
Limit Type
Upper
X to CF
Relative
Y to Ref
Relative
Margin
Off, 0 dB
Frequency
0 Hz
Amplitude
0 dBm
Build From Trace
Trace1
X Offset
0 Hz
Y Offset
0 dB
Select Limit
Limit1
Limit Type
Upper
X To CF
Fixed
Y To Ref
Fixed
Margin
Off, 0 dB
Test Trace
Trace1
Test Limits
On
Limit State
Off
T-Power
Avg Number
10
Avg Mode
Exponential
Avg State
On
TP Type
Peak
Start Line
0 us
Stop Line
1 ms
ACP
Avg Number
10
Avg Mode
Exponential
