key display description
INFO Access to information menu, various system statuses, temperatures and operating information can be called up here.
IN INFORMATION INPUTS
FLAME
319
Display of current flame temperature
MENU
ROOM
22
Display of current room temperature
MENU
R-MAX Display menu maximum duration without connection to wireless room sensor
MENU
EXTON Display of status of external release (ON or OFF)
MENU
DOOR ON Display of the status of door contact (ON or OFF)
MENU
STB ON Display of the status of safety temperature limiter (ON or OFF)
MENU
GRID ON Status display for the mudhole door contact (ON or OFF)
MENU
IN INFORMATION INPUTS
MENU
OUT INFORMATION OUTPUTS
AUGER OFF Display of operating status of screw motor (ON or OFF)
MENU
AUGER 0 Display of actual push-in rate
MENU
FAN ON Display of operating status of flue gas blower (ON or OFF)
MENU
FAN 0 Display of speed of flue gas blower
MENU
C-FAN OFF Display of the operating status of the optional cross-flow fan (ON or OFF)
MENU
C-FAN 0 Display of the speed of the cross-flow fan
MENU
GRID OFF Display of the operating status of the mudhole door motor (ON or OFF)
MENU
IGNIT OFF Display of operating status of ignition element (ON or OFF)
MENU
OUT INFORMATION OUTPUTS
MENU
PAR INFORMATION PARAMETER
RUN - T
63
Display of previous total operating hours
MENU
RUNKG
245
Display of total pellet amount supplied up to present
MENU
SERKG
245
Display of conveyed pellet amount since the last cleaning and maintenance
MENU
TPO 0144 Display of current software version loaded on control board (Scrolling text)
MENU
PMSM-VER 004 Display of the current software version of the auxiliary board (Scrolling text)
MENU
U-VER 17 Display of current software version loaded on control unit
MENU
PAR Repeated pressing returns you to the main menu level.
