2. CONTENTS
3. CONTROLS
1 – Auto Tester
2 – Test leads with probes x2
3 – Test leads with baery clamps x2
4 – Current adapter
1 - Selector dial
2 - Connuity mode
3 - Current mode
4 - Voltage mode
5 - Resistance mode
6 - Frequency mode
7 - POWER & ENTER buon
8 - BACK buon
9 - Direcon buons
10 - LCD display
11 - Status indicator
12 - Negave(-) connecon
13 - Posive(+) connecon
1 2
3
4
1
7
9
2
10
8
3
11
6
4
12
5
13
3
