RSC904 / RSC906 / RSC908
4 A / 6 A / 8 A SMART
BATTERY CHARGER AND MAINTAINER
For all battery types, including lithium
9
10 11
6 V / 12 V / 24 V ?
RSC904 (4 A) RSC906 (6 A) RSC908 (8 A)
230 V AC 50 Hz /
≤ 0.7 A
230 V AC 50 Hz /
≤ 1.1 A
230 V AC 50 Hz /
≤ 1.5 A
6 V: ≤ 7.4 V 12 V: ≤ 14.8 V 6 V: ≤ 7.4 V 12 V: ≤ 14.8 V 12 V: 14.8 V 24 V: 29.0 V
6 V: ≤ 2 A 12 V: ≤ 4 A 6 V: ≤ 3 A 12 V: ≤ 6 A 12 V: ≤ 8 A 24 V: ≤ 4 A
6 V: ≤ 40 Ah 12 V: ≤ 90 Ah 6 V: ≤ 50 Ah 12 V: ≤ 110 Ah 12 V: ≤ 150 Ah 24 V: ≤ 70 Ah
