ring Transformer User Manual

Wire Length *
0-50 Feet 51-100 Feet 101-150 Feet
Total Light Wattage
0-50
Watts
16 AWG 16 AWG 14 AWG
51-100
Watts
16 AWG 14 AWG 12 AWG
100-200
Watts
14 AWG 12 AWG 12 AWG with
15V Tap **
* Make sure your cable is long enough to reach all light fixtures. Consult cable manufacturer if
additional wire length or connectors are needed.
** Only use 15V Tap when the wire length is over 100 feet and total wattage is over 100 Watts.
12V Tap is recommended for all other cases.
*** Use ONLY with common gauge sizes of CSA or UL approved low voltage cable (12-16 AWG).
Calculate the total fixture wattage.
Ensure the total fixture wattage does not exceed the
maximum wattage load of the Transformer.
To get the total wattage, add up the wattage of each
fixture (example: 10 fixtures at 5W each is 50W total
wattage).
Place light fixtures.
Decide where you would like to place your lights
(not included), and arrange them in the desired
locations.
1110

ring Transformer Specifications

General

Brand	ring
Model	Transformer
Category	Controller
Language	English
