Rinnai Control-R RWM101 User Manual

To protect yourself from harm, follow the steps below
before wiring the module:
• Turn off the electrical power supply by unplugging the
power cord or by turning off the electricity at the circuit
breaker. The temperature controller does not control the
electrical power.
• The steps in this section must conform with local codes
and the guidelines established by the National Electrical
Code (NEC).
WARNING
Unplug the water heater power cord (pressing the
ON/OFF button on the controller does not power off
the water heater).
Remove the water heater front panel by removing
the four screws that secure the panel.
❶
❷
Connect the module wires to the PC Board located
inside the water heater:
❸

Rinnai Control-R RWM101 Specifications

General

Brand	Rinnai
Model	Control-R RWM101
Category	Wireless Router
Language	English
