36
Manual - Rinnai Condensi
ng Water Heaters
T
echnical Data
Pressure
Drop
Curve
Outlet
Flow
Data
RC98HP
Water Flow (gpm)
delta T - Temperature Rise (ºF)
Pressure Loss (ft head)
Water Flow (gpm)
Pressure Loss (psi) )
RC98HP
The chart below only applies to incoming water tem
peratures of 70°F (21°C) o
r less. For
incoming water temperatures greater than 70°F
(21°C) please contact Rinnai.
NOTICE
RC80HP
RC80HP
35
37
