Rinnai REU-KA2530FFUD-US User Manual

Condensing Water Heater Service Manual 45 100000354
KB Series Component Replacement Instructions
RU80i/e, RU98i/e
Heat Exchanger
13.Remove 6 screws at top of heat exchanger. (FIGURE 7)
FIGURE 7
14.Remove 4 screws at bottom of heat exchanger. The heat exchanger can now be removed from the cabinet. Be
careful not to handle the heat exchanger by the plastic black air box on the back so as not to damage the air intake.
(FIGURE 8)
FIGURE 8
