Rinnai REU-KA3237FFUD-US User Manual

Condensing Water Heater Service Manual 51 100000354
KA Series Manifold Gas Pressure Settings
Dip Switch
Setting
Altitude
Natural Gas (Gaz Naturel) Propane Gas (Gaz propane)
MAX VENT
Dip Switch #1 is OFF
MIN VENT
Dip Switch #1 is ON
MAX VENT
Dip Switch #1 is OFF
MIN VENT
Dip Switch #1 is ON
Max Rate
inches
W.C.
Min Rate
inches
W.C.
Max Rate
inches
W.C.
Min Rate
inches
W.C.
Max Rate
inches
W.C.
Min Rate
inches
W.C.
Max Rate
inches
W.C.
Min Rate
inches
W.C.
RC80HPi (REU-KA2530FFUD-US) #2 OFF, #3 OFF 0-2000 ft (0-610 m)
3.00 0.81 2.90 0.70 3.80 1.11 3.7 1.06
#2 OFF, #3 ON 2001-5200 ft (610-1585 m)
2.90 0.70 3.20 0.70 3.80 0.90 3.9 0.70
#2 ON, #3 OFF 5201-7700 ft (1585-2277 m)
2.90 0.55 2.90 0.55 3.80 0.90 3.9 0.55
#2 ON, #3 ON 7701-10200 ft (2277-3109 m)
2.90 0.55 2.85 0.55 3.40 1.00 3.5 0.55
RC98HPi (REU-KA3237FFUD-US) #2 OFF, #3 OFF 0-2000 ft (0-610 m)
2.70 1.08 2.40 0.85 4.00 1.46 3.60 1.22
#2 OFF, #3 ON 2001-5200 ft (610-1585 m)
2.40 0.80 2.40 0.80 3.60 1.30 3.30 1.10
#2 ON, #3 OFF 5201-7700 ft (1585-2277 m)
2.40 0.80 2.40 0.80 3.60 1.20 3.30 1.10
#2 ON, #3 ON 7701-10200 ft (2277-3109 m)
2.40 0.80 2.40 0.90 3.20 1.10 3.20 1.00
Dip Switch Setting Altitude
Natural Gas (Gaz Naturel) Propane Gas (Gaz propane)
Max Rate
inches W.C.
Min Rate
inches W.C.
Max Rate
inches W.C.
Min Rate
inches W.C.
RC80HPe (REU-KA2530WD-US) #2 OFF, #3 OFF 0-2000 ft (0-610 m)
2.70 0.61 3.60 0.92
#2 OFF, #3 ON 2001-5200 ft (610-1585 m)
2.90 0.60 3.70 1.00
#2 ON, #3 OFF 5201-7700 ft (1585-2277 m)
2.90 0.60 3.70 1.00
#2 ON, #3 ON 7701-10200 ft (2277-3109 m)
2.90 0.60 3.40 1.00
RC98HPe (REU-KA3237WD-US) #2 OFF, #3 OFF 0-2000 ft (0-610 m)
2.20 0.63 3.10 1.00
#2 OFF, #3 ON 2001-5200 ft (610-1585 m)
2.20 0.70 3.10 1.00
#2 ON, #3 OFF 5201-7700 ft (1585-2277 m)
2.20 0.70 3.10 1.00
#2 ON, #3 ON 7701-10200 ft (2277-3109 m)
2.20 0.70 3.00 1.00
