Rinnai RL75i REU-VC2528FFUD-US User Manual

8 VCSeriesManual
24"
V
Checkonwhetherlocalcodessupersedetheseclearances.
x AvoidterminaƟonlocaƟonsnearadryervent.
x AvoidterminaƟonlocaƟonsnearcommercial
cookingexhaust.
x YoumustinstallaventterminaƟonatleast12
inchesfromtheground.
60"
V
V
(1.52m)
between
terminalsat
diīerentlevels
(0.61m)towallorparapet

(0.30m)between
terminalsatsame
level
12"
V V
(1.52m)verƟcally
betweenterminals
V
60"
V
AddiƟonalclearancesͲRL75i,RL94i
12"
12"
36"
INSIDE
CORNER
VV
(0.30m)to
aninside
corner
(0.30m)between
terminalsatsame
level

ImportantconsideraƟonsforlocaƟngvent
terminaƟonunderasoĸt(venƟlatedorunvenƟlated
oreavevent;ortoadeckorporch)
x DonotinstallventterminaƟonunderasoĸtvent
suchthatexhaustcanenterthesoĸtvent
x InstallventterminaƟonsuchthatexhaustand
risingmoisturewillnotcollectunder
eaves.DiscoloraƟontotheexteriorofthe
buildingcouldoccurifinstalledtooclose.
x DonotinstalltheventterminaƟontooclose
underthesoĸtwhereitcouldpresent
recirculaƟonofexhaustgasesbackintothe
combusƟonairintakepartoftheterminaƟon.

Rinnai RL75i REU-VC2528FFUD-US Specifications

General

Model Number	RL75i REU-VC2528FFUD-US
Type	Tankless
Fuel Type	Natural Gas or Propane
Flow Rate	7.5 GPM
Energy Factor	0.82
Ignition Type	Electronic
Venting	Direct Vent
Warranty	5 years parts
