6. Specifications :
Feature:
Display 3 Digit 7 Segment Display(14mm digit height)
Parameter Displayed Power Factor
Technical Data:
Weight 0.25Kg.
Case Panel Mounted Instrument
96 x 96 x 35 mm
(Back Depth 55mm with Add on Module)
(Cut Out 92+0.8 x 92+0.8 mm)
Ambient Conditions
Over Voltage Class III
Polution Degree 2
Operating Temperature 0..+55 °C
Storage Temperature -20...+65 °C
Sensitivity to EMC IEC61326-1:2010
Safety Guidelines IEC61010-1:2010
Mounting Position Flush Mounting
Humidity Class 15%...95% Non Condensing
High voltage test 2.5 kV AC , 50 Hz for 1 minute between all
all electrical circuits
Protection Class:
Front Plate IP50 as per IEC60529
Back Plate IP20 as per IEC60529
Operation:
Auxiliary Supply Voltage 80 Vac - 300 Vac
Auxiliary Supply Frequency 50 Hz
Auxiliary VA burden < 8 VA Approx. (With 8 Relay on )
Target cos phi 0.8 Lag...0.8 Lead programmable
