1. Introduction
The Power Factor Controller is a modern
control device of innovative design with
auto bank detection function.
It is designed for a measuring voltage of
80 to 300 Vac. Display of Power Factor with
Auto Detection Function makes ease of
operation.
Main Features:
- 4/6/8 switching outputs.
- Autoitialisation function for Minimum settings
CT ratio is optional
Bank kVAr detection
Phase correction angle detection
Number of bank detection
- Various bank kVAr input method
Programmable individual bank kVAr value,
Auto detection of bank value,
1- 9 standard control series.
- Fault detection for Under Voltage, Over Voltage and Under Current.
- Capacitor bank protection by switching off capacitor bank for faults.
- Manual relay test mode
- Ultra bright LED Display.
- Compact size of 96 x 96 with low back depth.
- Adaptable to 144 x 144 panel cutout by use of adapter plate.
- Onsite Programmable PFC parameters
L1
L2
L3
V
x1000
LAG
LEAD
PF
2
