20
1. Refer to page 5 for detailed drawing.
2. Place left and right hitch on stands approximately 30” off ground (item 1). (Ensure decals are right
side up).
3. Leave all bolts loose until directed to tighten.
4. Bolt hitch tie retainers, top and bottom pieces to hitch using capscrews, washers and stover lock
nuts (items 1, 4, 6, 16 & 20).
5. Use capscrew, stover lock nuts to connect hitch sides at the front of hitch assembly (items 17, 22 &
28).
6. Bolt hydraulic tongue and electrical holder to hitch using capscrew, washer and stover lock nut
(items 13, 16, 21 & 26), snug these bolts.
7. Bolt hitch tongue attachment to main hitch assembly using capscrew, stover lock nut (items 18 &
23), snug these bolts.
8. Attach Perfect Hitch to hitch tongue attachment using 1” x 7” capscrew and 1” stover lock nut.
(items 24, 27 & 19), these bolts can be torqued.
9. Place side winder jack on unit (item 9). Bolt the manual tube on to the hitch using the 3/8” x 1-1/4”
capscrew, 3/8” flat washer and 3/8” stover lock nut (items 11, 12, 13, 15 & 25).
10. The hitch assembly can now be attached to the centre frame using 3/4” x 2-1/2” capscrews and
3/4” stover lock nuts (item 1, 23, 29 & 18). All bolts can now be torqued to specs.
1. Refer to page 7 for detailed drawing.
2. Set centre frame on level ground with the drum chocked to keep from rolling and braced frame front
and back to keep frame horizontal.
3. Make sure the walking arm and centre axles are pulled away from the centre frame.
4. Attach the hitch assembly to the centre frame, this will help stabilize the unit.
5. Remove the pins for the auto fold hook weldment. (front on centre frame).
6. Place the auto fold hook weldment into the centre frame lugs, use auto fold pin, machinery washer
and cotter pin (items 3, 4, 5, 17 & 18). This will have to be matched as required with the telescopic
swing arm.
7. Attach the cylinder base to the centre frame lug, use cylinder pin (item 1, 3, 16 & 18).
8. Attach the cylinder stroke to the auto fold hook weldment use the cylinder pin (item 1, 4, 6, 16 &
18).
