1. Refer to page 9 for detailed drawing.
2. Begin by threading one 1/2” hex nut halfway down the threaded rod (items 3 & 12). Next, place the
tension pipe on the threaded rod, followed by the second hex nut and the 1/2” jam nut (items 6, 12
& 22). Thread the jam nut far enough so that 4 or 5 threads are visible from the jam nut to the edge
of the threaded rod (approximately 1/2”). Now tighten the hex nuts against the jam nut. Finally,
once you have everything tight; hook the tension spring on the tension rod assembly. (Refer to pag-
es 7 & 8).
3. Place the tension rod assembly inside the outer telescopic swing arm half, tension pipe in first
(items 2 & 3).
4. Place the inner telescopic swing arm half inside the outer telescopic swing arm half (items 1 & 2).
Insert the 1/2” x 4-1/2” capscrew through the inner telescopic swing arm half (items 10 & 22) make
sure to thread the capscrew through the spring end of the tension spring inside the assem-
bly. Place 1/2 stover on bolt and tighten (item 12). Be careful not to unhook the spring prior to
complete assembly.
5. Place the two 3/8” x 4-1/2” bolts (item 10) through the outer telescopic swing arm half, starting with
the bottom one these bolts will have to thread through the spring retainer pipe (item 22).
Place the bolt in angling it down, then pry the bolt up on the tension rod assembly to get it through
completely. Next place the second bolt in, followed by threading the two 3/8” stover (item 11) onto
the bolts and tightening. Pull on the assembly to make sure spring is still attached.
6. Place the swing arm pin in the centre frame. Once you have the inner swing arm in the centre
frame pry out the inner far enough from the outer swing arm half you can place the slider stop plate
on the inner swing arm half, while continuing to pry the halves apart. Thread the two 1/2” x 1” bolts
with lock washers through the slider stop plate and into the inner swing arm (items 9, 17 & 22).
With the shorter half of the slider stop plate towards the 1” swing arm pin. Finally, tighten the two
1/2” x 1” bolts.
