22
1. Refer to page 11 for detailed drawing. Refer to Page 27 & 28 Section 1 for installation dimensions.
2. Attach draft arm pin to telescopic swing arm using pin 3/4” x 1-3/4” capscrew, spring lock washer
and flat washer (items 34, 18, 21 & 26).
3. Attach draft arm to telescopic swing arm using swing arm pin, bushing and 1” stover lock nut (items
2, 8, 32 & 14) thread the draft arm swivel ball joint through and then tighten see #5.
4. Attach the draft arm clevis to the wing using the 3/4” x 6-1/16” x 5-3/4” inside leg length Sq. U-Bolt
and stover lock nut (items 16, 19 & 22). Refer to insert for proper location of draft arm, sizes, clevis
locations and draft clevis hole locations.
5. Attach the opposite end of the draft arm to the wing clevis using cylinder pin weldment, machine
washers, draft arm spacers and cotter pin (items 6, 24, 29 & 33).
1. Refer to page 13 for detailed drawing.
2. Attach the walking arm weldment (item 3) to the centre frame using two walking arm pin weldments
(item 9), capscrews and stover lock nuts (items 22, 26 & 33).
3. Put a good even coat of anti-seize on the long plated walking arm pins (item 39).
4. Attach centre axle upper link weldment to the walking arm using long plated walking arm pin (items
7, 18, 21, 30, & 39).
5. Attach walking arm hook weldment to the walking arm using long plated walking arm pin (item 7,
18, 21, 30, & 39).
6. Attach centre axle lower link weldment (item 6), lower centre axle link arm painted (item 41), and
the stroke of the 4” x 12” cylinder (item 2) to the centre axle upper link weldment (item 7) using a 1”
x 7-1/2” capscrew (item 28), with 1” flat washers (item 32) between the centre axle upper link weld-
ment and the centre axle lower link weldments and 1” stover lock nut (item 23).
7. Attach base of 4” x 12” cylinder to the centre frame using 1” x 8-3/4” useable pin weldment (Page
38, items 9, 23 & 27).Attach centre axle weldment (item 6) to walking arm weldment (item 4) using
centre axle pin weldment (item 8, 22, 26, 27, 31, 33 & 36), 3/4” x 2” capscrew, 3/4” split lock wash-
er, 3/4” flat washer plated.
8. Attach centre axle weldment (item 5) to centre axle lower link weldments (item 6 & 41) using 1” x 7-
1/2” capscrew and 1” stover lock nut (23 & 28).
9. Attach base of 2-1/2” x 6” cylinder to walking arm weldment (items 1 & 3) using 1” x 3-1/2” OD cyl-
inder pin, and two 3/16” x 2” cotter pins (items 37 & 38).
