12 Rittal fan-and-filter unit assembly and operating instructions
Technical specifications
EN
Unit Model No.
Fan-and-filter unit
RAL7035
3239.100 3239.110 3239.124
Fan-and-filter unit
RAL9005
3239.108 3239.118 –
EMC fan-and-filter unit
RAL7035
3237.600 – –
Rated operating voltage
V
Hz
230, 1~,
50/60
115, 1~,
50/60
24 (DC)
Rated current max. A 0.12/0.11 0.24/0.22 0.23
Power consumption W 19/18 5.5
Pre-fuse T A 2
Dimensions
Width (B1) x height (H1) mm 204 x 204
Required mounting cut-
out (B2 x H2)
mm 177 x 177
Depth (T1) mm 24
Max. installation depth
(T2)
mm 90
Air throughput, unimped-
ed airflow with standard
fleece filter mat
m³/h 100/115 100
Air throughput, unimped-
ed airflow with pleated
filter
m³/h 110/125 110
Air throughput with outlet
filter, including standard
fleece filter mat
m³/h
1 x 3239.20x: 74/87
2 x 3239.20x: 84/98
Air throughput with outlet
filter including pleated filter
m³/h
1 x 3239.20x: 89/100
2 x 3239.20x: 98/112
Outlet filter RAL 7035 3239.200
Outlet filter RAL 9005 3239.208
EMC outlet filter
RAL7035
3239.060
Fan Axial, shaded pole motor Axial, DC motor
Noise pressure level dB (A) 46/49 46
Operating temperature °C -15…+55
Storage temperature °C -30…+70
Protection category (to
IEC 60 529)
IP54 standard
IP55 with pleated filter
IP56 with hose-proof hood
Tab. 4: Technical specifications Technical modifications reserved.
