Rittal fan-and-filter unit assembly and operating instructions 13
Technical specifications
EN
Unit Model No.
Fan-and-filter unit
RAL7035
3240.100 3240.110 3240.124 3241.100 3241.110 3241.124
Fan-and-filter unit
RAL9005
3240.108 3240.118 – 3241.108 3241.118 –
EMC fan-and-filter unit
RAL7035
3240.600 – – 3241.600 – –
Rated operating voltage
V
Hz
230, 1~,
50/60
115, 1~,
50/60
24 (DC)
230, 1~,
50/60
115, 1~,
50/60
24 (DC)
Rated current max. A 0.21/0.19 0.42/0.38 0.43 0.26/0.24 0.52/0.48 0.8
Power consumption W 35/34 10 40/42 19
Pre-fuse T A 2 4 2 4 2
Dimensions
Width (B1) x height (H1) mm 255 x 255
Required mounting cut-
out (B2 x H2)
mm 224 x 224
Depth (T1) mm 25
Max. installation depth
(T2)
mm 107
Air throughput, unimped-
ed airflow with standard
fleece filter mat
m³/h 175/155 175 225/245 225
Air throughput, unimped-
ed airflow with pleated
filter
m³/h 218/188 218 272/272 272
Air throughput with outlet
filter, including standard
fleece filter mat
m³/h
1 x 3240.20x: 130/110 1 x 3240.20x: 171/182
2 x 3240.20x: 159/135 2 x 3240.20x: 200/217
Air throughput with outlet
filter including pleated filter
m³/h
1 x 3240.20x: 188/157 1 x 3240.20x: 237/228
2 x 3240.20x: 207/177 2 x 3240.20x: 261/257
Outlet filter RAL 7035 3240.200
Outlet filter RAL 9005 3240.208
EMC outlet filter
RAL7035
3240.060
Fan
Diagonal, selfstarting
shaded pole motor
Diagonal,
DC motor
Diagonal, selfstarting
shaded pole motor
Diagonal,
DC motor
Noise pressure level dB (A) 51/46 51 54/56 54
Operating temperature °C -30…+55
Storage temperature °C -30…+70
Protection category (to
IEC 60 529)
IP54 standard
IP55 with pleated filter
IP56 with hose-proof hood
Tab. 5: Technical specifications Technical modifications reserved.
