14 Rittal fan-and-filter unit assembly and operating instructions
Technical specifications
EN
Unit Model No.
Fan-and-filter unit
RAL7035
3243.100 3243.110 3244.100 3244.110 3244.140 3245.500 3245.510
Fan-and-filter unit
RAL9005
3243.108 3243.118 3244.108 3244.118 – 3245.508 3245.518
EMC fan-and-filter unit
RAL7035
3243.600 – 3244.600 – – 3245.600 –
Rated operating voltage
V
Hz
230, 1~,
50/60
115, 1~,
50/60
230, 1~,
50/60
115, 1~,
50/60
400, 3~,
50/60
460, 3~,
60
200…240
1~,
50/60
100…130
1~,
50/60
Rated current max. A 0.37/0.39 0.78/0.8 0.43/0.6 0.9/1.25 0.17/0.21 1.33 2.1
Power consumption W 70/87 75/90 95/135 100/145 93/140 165 165
Pre-fuse T A 4 6 4 6
Motor
circuit
breaker
4 6
Dimensions
Width (B1) x height (H1) mm 323 x 323
Required mounting cut-out
(B2 x H2)
mm 292 x 292
Depth (T1) mm 25
Max. installation depth (T2) mm 118.5 130.5 130.5
Air throughput, unimped-
ed airflow with standard
fleece filter mat
m³/h 540/590 700/770 890
Air throughput, unimpeded
airflow with pleated filter
m³/h 625/716 855/905 1125
Air throughput with outlet
filter, including standard
fleece filter mat
m³/h
1 x 3243.20x: 405/460 1 x 3243.20x: 485/520 1 x 3243.20x: 630
2 x 3243.20x: 475/520 2 x 3243.20x: 570/630 2 x 3243.20x: 770
Air throughput with outlet
filter including pleated filter
m³/h
1 x 3243.20x: 550/630 1 x 3243.20x: 700/730 1 x 3243.20x: 930
2 x 3243.20x: 600/683 2 x 3243.20x: 800/840 2 x 3243.20x: 1060
Outlet filter RAL 7035 3243.200
Outlet filter RAL 9005 3243.208
EMC outlet filter
RAL7035
3243.060
Fan Diagonal, capacitor motor
Diagonal,
rotary
current
motor
Diagonal, EC motor
Noise pressure level dB (A) 59/61 65/66 67/70 72
Operating temperature °C -30…+55
Storage temperature °C -30…+70
Protection category (to
IEC60 529)
IP54 standard
IP55 with pleated filter
IP56 with hose-proof hood
IP51 standard
IP52 with pleated filter
IP56 with hose-proof
hood
Tab. 6: Technical specifications Technical modifications reserved.
