Ritter 204 - Product Operation Guide; Back Section Adjustment

© Midmark Corporation 2020
English - 8
003-10362-99
TP202 20-42-FO-00014 Rev A1 C2169
Operation
Back Section Positioning
To position the back section...
A) While holding the back section in place, squeeze the
Back Release Handle (either side).
B) Move the back section to desired position.
C) Release handle to lock back section in position.
MA697500i
Max.
70° ±5°
Min.
0° ±1°
Back Release Handle
