Ritter 222 - Paper Roll and Tear Strap Installation

9
Paper Roll & Tear Strap
Note
Up to four paper rolls (max.) may be stored under the back section.
Paper Roll Size (maximum):
222 & 223 (-015 & -016).......................................... 21 in. long x 3.5 in. diameter
(53.3 cm x 8.9 cm)
222 (-017) ............................................................... 19.7 in. long x 4.7 in. diameter
(50 cm x 12 cm)
MA631302i
To install the paper roll...
Insert rod ends into sockets under head end of upholstery.
To install the paper tear strap...
Attach strap to snaps on each side of table.
