15
Specifications
Weights, Dimensions, Electrical Specifications
Patient Weight (Maximum) ............................................... 400 lbs (181.4 kgs)
Paper Roll (maximum size): ............................................ (See
Paper Roll & Tear Strap
page)
Range of Motion &
Dimensions ..................................................................... (See
Range of Motion & Dimensions
page)
Weight of Table:
[Weights listed are for 115V models. The 230V transformer adds 14.5 lbs (6.5 kg)]
222 / 223 w/upholstery .................................................. 325 lbs (147.4 kg)
w/packaging & skid
(no upholstery) .............................
375 lbs (192.7 kg)
Upholstery w/packaging
(shipped separately) ...........
40 lbs (18.1 kg)
Power Cord(s)
[115V models have two cords]
: ............... 8 ft. (243.8 cm) long
Electrical Requirements: ................................................. [See
Regulatory Compliance Charts
]
Foot Control Voltage: ........................................................ 14 VAC, SELV (Safety Extra Low Voltage)
Duplex Receptacle (optional)
maximum load: ...............................................................
115 VAC, 5A
Fuses:
222/223
(all)
:
F1 & F2
(on main PC board) ...............................................................
10A, 250V, Slo-Blo, 1/4" x 1 1/4"
F3
(on main PC board) ..........................................................................
5A, 250V, Slo-Blo, 1/4" x 1 1/4"
F4
(on main PC board) ...........................................................................
187 mA, 250V, Slo-Blo, 1/4" x 1 1/4"
223
(only):
F5
(on main PC board) ...........................................................................
4A, 250V, Slo-Blo, 1/4" x 1 1/4"
Models w/ drawer heater:
distribution board fuses (2) ............................................ .800 mA, 250V, Slo-Blo, 5 x 20mm
222
(-017)
:
located next to IEC inlet (2) ............................................ 4A, 250V, Slo-Blo, 5 x 20 mm
Duty Cycle:
Actuator motor run time: ..................................................... Intermittent Operation
[30 seconds ON / 5 minutes OFF]
Receptacle / Drawer Heater: ................................................ Continuous Operation
Classifications: ................................................................. Class 1, Type B Applied Part,
Intermittent Operation
Protection against ingress of fluids: .............................. IPX0, Ordinary Equipment
Equipment not suitable for use in the presence of a flammable anesthetic mixture with air,
or with oxygen, or nitrous oxide.
