BLOCKSYSTEM FA 6 REV. 02 02/03
UK
7. 4
HOW TO CHANGE THE PARAMETERS
A fixed set of parameters in the memory of the controller regulates the function of the Blocksystem.
(acc.to schedule). We recommend only to change these values when necessary by experts.
To enter the programming menu, press the „SET“key for more than 5 sec. The label of the
parameter appears. To scroll through the other parameters, use the “UP” and “DOWN” keys. To
change the parameter, press and relese “SET”. Then set the desired value with the “UP” and
“DOWN” keys, and confirm with the “SET” key to move to the next parameter
.
SCHEDULE OF PARAMETERS
default
Par. description range level U.M. TN BT AT
Compressor regulator (folder "cp")
diF differential 0.1...30.0 1 °C/°F 2 2 2
HSE Higher SET LSE..30.0 1 °C/°F 8 -15 10
LSE Lower SET -50.0...HSE 1 °C/°F -5 -25 2
OSP Offset Setpoint (weekend,vacation) -30.0...30.0 2 °C/°F 0 0 0
Cit Compressor min.ON-time 0...250 2 Min 0 0 0
Cat Compressor max.ON-time 0...250 2 Min 0 0 0
dOd Digital imput Open micro-door n/y 2 flag N N N
dad Digital imput Activation delay 0…250 2 Min 0 0 0
Compressor protective devices ( folder "cp")
Ont On time (compressor) 0...250 1 Min 10 10 10
OFt OFF time (compressor) 0...250 1 Min 10 10 10
dOn Power-On delay 0...250 1 Sek 0 0 0
dOF Delay after power - OFF 0...250 1 Min 0 0 0
dbi Delay between power - on 0...250 1 Min 0 0 0
OdO Delay Output power on 0…250 1 Min 3 3 3
Defrosting regulator ( folder “def)
dty Defrost type 0 = electric; 1 = Hotgas; 2 –compressor stop 0/1/2 1 flag 1 1 2
dit Defrost intervall time 0…255 1 num 5 5 5
dt1 Unit for “dit” 0 = Hrs.; 1 = Min.; 2 = Sec. 0/1/2 2 flag 0 0 0
dt2 Unit for “dEt” 0 = Hrs.; 1 = Min.; 2 = Sec. 0/1/2 2 flag 1 1 1
dCt Defrost Counting type:
1 = compressor running time; 2 = Operation time;
3 = Compresor OFF
0/1/2 1 flag 0 0 0
dOH Defrost Offset Hour 0...59 1 Min 0 0 0
dEt Defrost Endurance time 1...250 1 num 30 30 30
dSt Defrost Stop temperature -50...150 1 °C/°F 10 15 10
dPO Defrost (at) Power On n/y 1 flag n n n
tcd Time compressor (for) defrost -31...31 2 min 0 0 0
Cod Compressor off (before) defrost 0…60 2 min 0 0 0
Fans regulator ( folder "Fan")
FPt Par. 'FSt' 0 = absolut ; 1 = relative to SET 0/1 2 flag 0 0 0
FSt Fan Stopp temperature -50…50 1 °C/°F 8 -5 50
Fot Fan on-start temperature -50…150 2 num -50 -50 -50
Fad Fan differential 1…50 1 °K 2 2 2
Fdt Fan delay time 0...250 1 min 1 2 0
dt Drainage time 0...250 1 min 2 2 0
dFd Defrost Fan disable n/y 1 flag y y n
FCO Fan compressor OFF.
Y = Fan ON (depending on „FSt“);
n = Fan OFF;
d.c. = Fan ON/OFF (Par. Fon and Fof).
N/y/d.c. 1 flag n n n
Fod Fan off (with opened) door N/y 2 flag n n n
Fdc Fan delay compressor off 0..99 2 min 0 0 0
fon Fan on in duty cicle 0..99 1 min 0 0 0
FoF Fan OFF in duty cicle 0..99 1 min 0 0 0
