RIVC000001 Pag. 11 REV. 00 11/10/10
UK
7. 2
Switching on/off
When the machine is energ
ised, the display will read OFF and show the coldroom temperature
alternately. To switch the Blocksystem on (off), hold down the “ON/OFF” key on the front of the machine
for more than 5 seconds.
7. 3
Coldroom temperature adjustment
The te
mperature ranges within which the Blocksystem can operate are as follows:
Minimum Maximum
High Temperature (HBP) +2 +10
Medium Temperature
(MBP)
-5 +5
Low Temperature (LBP) -25 -15
The temperature adjustment setpoint can be accessed directly for display or adjustment purposes.
• Press and release SETPOINT: the display will read “SEt” (the procedure is slightly
different if there
are alarms in
progress; see the machine status display
paragraph)
• Press
SETPOINT: the green SET LED will switch on and the Setpoint value will be
displayed
• Press U
P or DOWN to set the new va
lue
• Press
SETPOINT or ON/OFF (or wait for the 5-second timeout) to confirm the value (the SET
LED
w
ill switch off and the display w
ill read “SEt”)
• Press ON
/OFF (or wait for the 5-second timeout) to return to the normal display mode
7. 4
How to vary parameters
Blocksystem o
peration is governed by parameters that have been stored in the memory of the electronic
control unit by the manufacturer (see the parameters table). These factory settings should not be varied
unless strictly necessary, and in all cases such operations are only to be carried out by qualified staff.
Parameters are not only divided by function, they are also divided according to their security/accessibility
levels:
Level 0 Setpoint parameters direct access (see paragraph 7.3)
Level 1 frequently used parameters access without password (see paragraph 7.5)
Level 2 configuration parameters access with password (see paragraph 7.7)
Parameters can be varied as follows:
From the keyb
oard
Via LAN network (Maste
r/Sla
ve)
Via Supervision netwo
r
k
7. 5
How to vary level 1 parameters
Hold
down SET for 5 seconds until the display reads “reg” (adjustment parameters
)
Press U
P or DOWN until the required menu appears on
the display
Press
SET to access the menu; the code number for the first parameter in the selected menu will
appear
Press U
P or DOWN until the required parameter appe
ars
Press
SET to view the value
of the parameter
Press U
P or DOWN to set the required va
lue
Press SE
T to confirm the value and return to the parameters list; press ON/OFF to confirm the
value and return to the me
nu list
Press ON
/OFF to pass from the para
meters list to the menu list
Press ON/OFF again to exit the editing procedure,
If no key
is pressed for more than 15 seconds, any value shown on the display will be stored in the
memory for the relevant parameter and there will be a forced exit from the parameters variation
procedure.
7. 6
Machine status display
Press a
nd release SET: the display will read “SEt” or “AAL” if there are any alarms
in progress
Press U
P or DOWN until the required status is displaye
d
AAL
alarms in progress (if present)
SEt setpoint
