RiverGrille Chuck Wagon - Page 12

GR2045401-RG-00/GR2045406-RG-00 12 of 27 20150831-Ver1
7
8
Step 6
With the help of other people, place
the grill body on the grill cart.
Make sure the four latches on the legs
and grill body are tightly locked.
Step 7
1. Open the side shelves.
2. Open the wind shield.
3. Open the side wind shield.
Step 8
1. Assemble the towel racks (L) to
the side shelves with bolt (CC).
2.
Install a LR6/AA battery into the
igniter.
HARDWARE USED
Bolt 3/16” x 10 mm 4 pcs
LR6/AA Battery 1 pc
6
CC
Latch
1
1
3
2
3
DD
CC
L
CC
DD
AA Battery +ve
outside
