Operator's Manual
LOCKDOWN™ 21’ 360 1-MAN
23. After both top and bottom ratchet straps are
secured to the tree, use a haul line to pull the
assembled seat up into the treestand. SEE
FIGURE 20. Slide the seat onto the bottom seat
post (3). SEE FIGURE 20A.
24. To take the ladder stand down, rst check the
security of the ground level ratchets (16) and
stabilizer straps (48). First, with two people
holding the bottom of the ladder, climb up,
secure your safety harness to the tree and lower
the seat with a haul line. Then, remove the
two top ratchet straps (47). Then climb down
and reverse the set-up and use instructions to
complete the removal of the stand.
FIGURE 20
FIGURE 20 A
