Rivers Edge LOCKDOWN - Comprehensive Parts List

Check for parts online at w ww.HuntRiversEdge.com or call 800-345-6007
28
Operator's Manual
LOCKDOWN™ 21’ 360 1-MAN
NO EXTENSIONS AVAILABLE FOR THIS MODEL.
NEVER MODIFY OR EXCEED ORIGINAL STATED USE HEIGHT!
ITEM # PART # DESCRIPTION QT Y.
1 23603 KNOB SILENT LADDER 4
2 29712 SQ PLUG 22 MM 2
3 34725 SEAT POST BOTTOM 1
4 34726 SEAT POST TOP 1
5 34737 BUSHING PLASTIC SWIVEL
SEAT
1
6 35085 LADDER HAND RAIL 2
7 35086 PLATFORM BRACE 2
8 35129 STRAP GUIDE 6
9 35131 INSERT STABILIZER BAR
MOUNT
1
10 35189 MIDDLE LADDER SECTION 2
11 35191 TOP LADDER SECTION 1
12 35193 BOTTOM LADDER SECTION 1
13 35195 LADDER SECTION WITH
STABILIZER
1
14 35222 BOTTOM TREE BLADE 1
15 35374 INSERT SHOOTING RAIL 8
16 35715 LADDER RATCHET 2
17 36719 KNOB SILENT LADDER WITH
STUD
8
18 42671 SUPPORT BRACE 4
19 42674 SHOOTING RAIL 4
20 42679 SHOOTING RAIL HUB 4
21 42680 BACKREST TUBE 2
22 42682 ARMREST WITH VINYL DIP 2
23 42684 TOP TREE BLADE 1
24 42691 VERTICAL SUPPORT 4
25 42796 J TUBE W/ POCKET 2
ITEM # PART # DESCRIPTION QT Y.
26 42797 J TUBE EXTENSION 2
27 42800 PLATFORM 2
28 42802 CURTAIN 1
29 42804 SEAT FRAME 1
30 42806 SEAT ASSEMBLY 1
31 42808 BACKREST 1
32 42810 BACKREST SPREADER 1
33 42844 STABILIZER BAR 1
34 48042B WING NUT 2
35 48044B WING BOLT 1/4 X 13/4 IN 1
36 48057B WING BOLT 1/4 X 2-1/4 IN 1
37 48240B BOLT 1/4 X 11/2 IN 20
38 48250B BOLT 1/4 X 13/4 IN 10
39 48261B WASHER 1/4 IN 10
40 48270B BOLT 1/4 X 21/2 IN 12
41 48271B BOLT 1/4 X 21/4 IN 9
42 48273B BOLT 1/4 X 31/4 IN 4
43 48280B BOLT 1/4 X 3 IN 8
44 48752B NUT 1/4 IN 67
45 8909B BOLT 1/4 X 11/4 IN 4
ITEMS BELOW NOT SHOWN
46 30777 TETHER ROPE 1
47 35135 ASSEMBLY 8 FT RATCHET
STRAP W/ SHOOKS
2
48 35140 STABILIZER STRAP 21 FT 2
49 35159 RATCHET STRAP ASSEMBLY
8 FT
1
50 35743 LARGE CARABINER 1
51 40697 HARNESS 1
PARTS LIST
