Rivers Edge RE656 - Hardware Identification Chart; Tools for Assembly

38 1/4-20 X 1-1/4 IN Bolt - Qty 2
33 1/4-20 X 1-1/2 IN Bolt - Qty 7
34 1/4-20 X 2-1/4 IN Bolt - Qty 4
37 1/4-20 X 2-3/4 IN Bolt - Qty 4
35 1/4-20 X 3-1/4 IN Bolt - Qty 2
27
M6 Yellow Spacer
Qty 4
23
M6 Yellow Washer
Qty 14
36
1/4-20 Nut
Qty 25
26 M6 X 1 X 20 MM Bolt - Qty 2
28 M6 X 1 X 70 MM Bolt - Qty 1
30 M6 X 1 X 60 MM Bolt - Qty 2
25
M6 X 10 MM
Knob
Qty 2
29
M6 X 29 MM
Knob
Qty 2
32 1/4-20 X 2-1/2 IN Bolt - Qty 4
24
M6 x 50.8 MM Lockpin
Qty 8
Quick Tip: Cut page out to use as a reference tool while following assembly instructions
HARDWARE IDENTIFICATION CHART
Bolts shown are for size reference.
Extra hardware may be included in the parts bag.
TOOLS FOR ASSEMBLY (NOT TO SCALE)
7/16 IN Wrench - Qty 2
1/2 IN Wrench - Qty 2 4 MM
Allen Wrench
Included
