5
2.8.1 Jet 1 (jet nozzles)
2.8.2 Jet 2
2.8.3 Reversing valve and
massage jets
Massage pump Jet 1 will be switched on and off by pressing the Jet 1 but-
ton. Should the pump not be switched off manually it will automatically
start again after 15 minutes.
For models of the series I the filtration will be activated through the 2-speed
pump by pressing Jet 1. Die Bediensequenz ist wie folgt:
Press x 1: filtration on (if not yet set ion the display for filter cycles)
Press x 2: Jet 1 on
Press x 3: off
Jets are switched off automactically after 30 minutes.
Disinfection cycle: 60 minutes after the use of one of the massage
functions, the filter and ozone generator will switch on and run a
disinfection cycle for 30 minutes.
Pressing button „Jet 2“ switches Pump 2 on and off. If Pump 2 is not
switched off manually, the pump will be switched off automatically after
15 minutes. This button is also available when the pool has only 1 massage
pump.
The reversing valve on the side of the pool determines which jets are being
activated when the pump runs.
Mid-position: The water flows through all jets evenly. The valve should
always be in this position when the whirlpool is not in use.
Left-position: This is the massage setting for jet line 1.
Right-position: Massage setting for jet line 2.
The reversing valve can be moved in between these positions in order to
adjust the intensity of the massage individually. In order to do so, turn off the
jet pump, switch the valve, then turn on the jet pump again.
In addition, the intensity of the massage of the Super jets (and with some
models the Hydro Jets) can be adjusted by turning the nozzle.
When the pump runs on high speed, additional air can be added to the jets
while on position “Jet 1” or “Jet 2”. In order to do this, the air control on the
side of the pool needs to be opened by turning the lever. The air supply
should be closed after the pool has been used.
Start up and use
