8
OPERATION
The cold planer is an engine powered attachment intended for cutting asphalt or con-
crete surfaces. The performance of the attachment can vary greatly depending upon
how it is used and operated. Therefore, the recommended operating procedures con-
tained within this manual should be followed at all times for maximum productivity.
Prior to operating the attachment, read this entire manual. Follow all safety guidelines
in this manual and safety decals on the unit. Make sure that all guards, shields, and
decals are in place and in good condition prior to operation.
Attaching to Loader
Pin on style mounting
To attach the unit to the loader, start the loader and rotate the coupler out. Move
the machine forward and align the male bosses on the male portion of the loader
attach with the female bosses on the Roadhog. Insert pins and secure pins to boss-
es per the manufacturers recommended procedure.
Attaching to Loader
quick attach style mounting
To attach the unit to the loader, start the loader and rotate the quick coupler out.
Move the machine forward and align the
male portion of the quick attach on the loader with the female portion of the quick
attach on the Roadhog. Secure the quick attach per the manufacturers recom-
mended procedure.
WARNING
ALWAYS follow the loader manufacturers recommended procedures for mounting
attachments to the loader. Refer to attachment mounting instructions in the loaders
operating manual. Severe injury or death could result from crushing.
GENERAL CONTROL SYSTEM
Units can be operated from either the panel or using the radio controller. The
master panel has illuminated push buttons that change colors during operation which
indicate the following and provide visual feedback to the operator.
RED—indicates that a function cannot be operated.
GREEN—means it can be operated
Flashing GREEN—tells the operator which mode or function is currently active.
Amber—used to tell the operator the water kit is in auto mode and slave to the clutch.
