NO ITEM CODE DESCRIPTION QTY SYMBOL
1 001-3300S-E20 P.C.B MAIN BOARD 1
2 001-0000S-B90 P.C.B FILTER BOX 1
3 002-0790R-H00 I.C DSC-790R 1 IC1
4 002-1923F-G07 I.C BU1923F 1 IC403
5 002-2313L-B00 I.C PT2313L 1 IC601
6 002-04558-G00 I.C TJM4558 2 IC3.2
7 002-01140-A09 I.C LA1140 1 U1
8 002-03370-A09 I.C LA3370 1 U2
9 002-07384-J06 I.C TDA7384 1 IC401
10 002-07035-T00 I.C KIA7035 1 Q30
11 002-78L05-F00 I.C KIA78L05 1 Q29
12 003-BD435-B00 TRANSISTOR-NPN TO-126 BD435 1 Q1
13 003-3199Y-H03 TRANSISTOR C3199 NPN TO-92S 14
Q27.14.13.4.2.20.33.18.19.
17.21.12.24.25
14 003-01303-D00 TRANSISTOR D1303 5 Q5.6.7.8.10
15 003-01368-C00 TRANSISTOR B1368 1 Q23
16 003-0966Y-A02 TRANSISTOR A966 1 Q11
17 003-1267Y-A00 TRANSISTOR KTA1267Y 2 Q3.9
18 003-1271Y-A03 TRANSISTOR A1271 1 Q34
19 003-3203Y-D03 TRANSISTOR C3203 2 Q26.15
20 003-01923-A00 TRANSISTOR C1923 1 Q16
21 004-04001-000 DIODE IN4001 1 FILTER BOX
22 004-04148-000 DIODE IN4148 21
D4.28.30.27.25.24.44.21.38.39.
9.10.11.5.16.3.41.6.33.23.8
23 005-00033-A00 ZENER DIODE 1/2W 3.3V 1 ZD10
Bill of Materials
PAGE 1 OF 13
