FEATURES
The unit features a detachable front control panel, FM/FM stereo, CD/MP3 player the follow-
ing features:
• The best stations memory automatically memorizes the best (strongest) station in the or-
der of their strength (AS).
• Electronic Volume, Bass, Treble, Fader and Balance control.
• Precision electronic tuning with phase-lock loop (P.L.L.) circuitry.
• Programmable 18 preset memory tuning (6 each for FM1/ FM2 / FM3)
• Loudness control
• Manual / Auto (Seek) / up and down tuning control
• Band selector for FM1/ FM2 / FM3
• Display control (Frequency, Station Name, Program Type, Clock)
• Clock Function in RDS
• CD Repeat Function
• CD and MP3 files on CD/CD-R/CD-RW player function
• Preamplified Line-out
• Detachable front panel protects against theft
• Lighting system
• USB Port and SD/MMC Input
• RDS Function: PI (Program Identification) TA (Traffic Announcement)
PS (Program Service Name) PTY (Program Type)
AF (List of Alternative Frequencies)
TP (Traffic Program)
INSTALLATION
PRECAUTIONS
• Choose the mounting location carefully so that the unit will not interfere with the normal
driving functions of the driver.
• Avoid installing the unit where it would be subject to high temperatures, such as from direct
sunlight or hot air from the heater, or where it would be subject to dust, dirt or excessive
vibration.
• Use only the supplied mounting hardware for a safe and secure installation.
• Be sure to remove the front panel before installing the unit.
Mounting angle adjustment
Adjust the mounting angle to less than 20°.
MOUNTING EXAMPLE
Installation in the dashboard
Note: Keep the release key in the safe place as you may need it in future to remove the unit
from the car.
Bend these
claws, if necessary
Release screw and
bracket
2
182mm
53mm
3
4
TAP
1
2
1
3
