Operating Manual
RO-Control NAVY Serie
No.8721
No.8722
No.8723
No.8724
Operating Manual
RO-Control Navy Serie
30 / 60 / 120 / 180 A
Brushless Electronic Speed
Controller
Art.-Nr.: xxxxxxxxxxxx
Art.-Nr.: xxxxxxxxxxxx
Art.-Nr.: xxxxxxxxxxxx
Art.-Nr.: xxxxxxxxxxxx
Dear customer, we are pleased that you have chosen a RO-Control Navy speed controller for
brushless motors from our range. This gives you a particularly powerful controller for controlling
your rc-boats engine.
Despite the relatively simple operation of these controllers, their use requires some knowledge from
you. These instructions will help you to familiarize yourself quickly with the possibilities of the speed
controller. To achieve this goal safely and quickly, you should read these operating instructions
carefully before commissioning the controller. The following safety instructions and warnings are of
particular importance.
Brushless motors can be very dangerous. Any improper use can cause
personal injury and destroy the controller and the devices connected to it. We
strongly recommend that you read these operating instructions completely
before use. Since we have no control over the use, installation or
maintenance of the controller, we accept no liability for this product for any
damage or loss resulting from the use of the product.
We also accept no responsibility for damage or loss caused by unauthorized changes to our
product.
Remote-controlled models are not toys and may only be used by young people under 14 years of
age under the constant supervision of adults who are familiar with the construction, operation,
material and possible dangers. Construction, commissioning and operation of remote-controlled
models are dangerous and are the full responsibility of the operator. We expressly point out these
risks and accept no liability. Careful, well-considered handling during operation protects against
personal injury and property damage. Carry out maintenance and inspections of your models and
electronic devices at short, regular intervals. Check regularly that all fastenings are securely
fastened.
The controllers are only intended for use in battery- or battery-operated, remote-controlled models.
Any other operation is not permitted. Please note that despite many safety features, an
accidentally starting electric motor, e.g. due to a defect of the controller, has considerable risk
potential and can result in considerable injuries. We cannot check the handling of the controller
and reject any claim for damages due to failure, faulty operation or malfunction.
We assume no liability for personal injury, property damage and their consequences arising from
our delivery or work. Never operate a damaged regulator, e.g. due to exposure to water or
mechanical deformation, a crash or similar.
Make sure that you do not reverse the polarity of the battery, that you avoid short circuits, that
the drive motor is effectively suppressed and that the air can circulate freely. Use reverse
polarity protected connector systems.
No.8721
No.8722
No.8723
No.8724
Operating Manual
RO-Control NAVY Series
No.8721
No.8722
No.8723
No.8724
Page
2
All cables and connections should be well insulated. The regulator must not come into contact with
grease or oil. Only use the connectors, original parts and accessories recommended by us. Always
set the throttle to "Stop" before switching on the transmitter.
In addition, it is imperative that you observe the following notes:
• Make sure that all cables and connections are well insulated before connecting the controller to
other devices, as a short circuit can damage the controller.
• Ensure that all equipment is properly connected, poor connections may cause you to lose
control of your model ship and cause other unforeseen problems, personal injury, property
damage or destruction of the controller.
• Stop the controller if it gets too warm. Otherwise the controller and / or the motor will be
damaged.
• Never try to operate two brushless motors with only one controller, otherwise the controller will
fail.
• Always keep the propeller away from your body and other objects, as they can be very
dangerous.
• Protect the speed controller from vibrations, dust, moisture and mechanical stress!
• Always connect the drive battery to the controller just before starting the model. After landing,
disconnect immediately.
• The controller is equipped with a tarnish protection. Nevertheless, for safety reasons, be very
careful and cautious when plugging the battery into the controller to prevent personal injury.
• Even if the receiving system is switched off, but the battery is still connected to the controller,
there is a fundamental risk potential.
• Make absolutely sure that the controller is always operated within the values of the technical
data. Overloading can lead to damage, resulting in great dangers.
• Always follow the instructions for connecting and installing the controller.
• High currents cause the cables to heat up, which can cause fire or burns to the skin. Lay the
cabling accordingly and proceed very carefully.
• Be sure to follow the warnings of the manufacturer of the motor, battery and model you are
using.
• The controller must never be connected to the 230V AC mains.
• When operating a model ship, you must comply with all safety regulations so as not to
endanger yourself and others.
After use, please remove all batteries and dispose of them separately. Hand in old
electrically operated equipment free of charge at the municipalities' collection points
for electrical waste. The remaining parts belong in the household waste.
Thank you for your help!
• Protected against splash water and moisture to IP67, the controller is suitable for use
where water can get inside the model. After such use, the regulator must be cleaned and
dried so that the plugs do not oxidize.
