Tilting the Sharpening Belt Assembly
To assist in sharpening tools the ProEdge has a very useful feature in that the sharpening
belt assembly can be angled backwards to allow for a much more comfortable position when
sharpening at shallow angles.
- This is done by loosening the two screws by a quarter of a turn, next to the drive pulley and gently
moving the belt assembly to your desired angle
- When the belt assembly is tilted backwards the rear screw is accessed via the access slot in the
side guard as shown below
- When the desired angle is achieved, re-tighten the screws (nger tight) to secure the belt assembly
in place
Front screw
just below the
ngernail boss
bar - 1/4 of a
turn
Rear screw
- 1/4 of a turn
Access
slot
10
