Supplement POH DR400/120D, DR400/140B,
DR400/180R, DR400/200R, DR400/RP
Issue 3 – July 2014 Page 1 - 21
Heating Control Settings
Function
Pulled
Pushed
Control 0
- Button Lock
Heat ON/OFF
ON
OFF
Control 1
Heating ON/OFF
ON
OFF
Control 2
Defrost / Heating
FRONT
HEATING
WINDSHIELD
DEFROST
Control 3
Front / Rear select.
REAR
FRONT
Table 1-6 Heating Control Settings
Figure 1-6 Heat Control Placard, Right Cabin Side Wall
This STC installation has a fourth control (Control 0 in table above). It
must be OFF (Push) when cabin heat is not required (hot outside air
temperature)
