14
-
Fig. 4-17
FUEL TANK
BALANCER SHAFT
ROCKER ARM
PISTON
INTAKE VALVE
(
EXHAUST VALVE
)
PISTON RING
PISTON PIN
PUSH ROD
CONNECTING ROD
TAPPET
CAMSHAFT
CRANKCASECRANKSHAFT
SPARK PLUG
GOVERNOR GEAR
