USING ELECTRIC POWER
■
Make sure that the appliance is switched OFF before connecting it to
the generator.
■
Do not move the generator while it is running.
■
Be sure to ground the generator if the connected appliance is
grounded. Failure to ground unit may lead to electrical shock.
WARNING
CONTROL PANEL
(RGV2800)
AC 120V
AC BREAKER
ON
OFF
ENGINE SWITCH
DC OUTPUT DC BREAKER
ON
OFF
BATTERY CHARGE ONLY
DC 12V-8.3A
ON
OFF
31
5
78910
1 AC receptacle
2 Full power switch
3 Voltmeter
4 Key switch
(Electric starter type)
5 Engine switch
(Recoil starter type)
6 Idle control switch
7 No-fuse breaker
8 DC circuit breaker
9 DC output terminal
!0 Earth (Ground) teminal
