Installation position
A Minimum height from the hob surface to the underside face of the rangehood
600mm electric hob
650mm gas hob
Notes: If the instructions for the gas hob specify a greater distance, this has to be taken into account.
Any installation above 750mm will compromise performance.
B Vertical height from bottom of Rangehood to Fixing Plate mounting screws
323mm.
C Distance between mounting screw holes on Fixing Plate
100mm.
