4. Using the Electric Wheelchair
4.6.2 Battery Installation
(4) Inserting the Battery (Refer to Figure 4.6.2.1)
• Position the battery into the designated slot, aligning it in the direction as
indicated in the figure.
Figure 4.6.2.1
1
(3) Battery Removal (Refer to Figure 4.6.1.3)
• Remove the battery by sliding it in the direction indicated in the figure.
Figure 4.6.1.3
5
