30
4. Using the Electric Wheelchair
4.6 Battery
4
.6.1 Battery Disassembly
(2) Right Side of Battery Case (Refer to Figure 4.6.1.2)
• Manually rotate the right knob of the battery case.
• Turn the right knob to the unlocking position.
• Open the right battery buckle.
The vertical state of the knob
is unlocked
Figure 4.6.1.2
3
4
(1) Left Side of Battery Case (Refer to Figure 4.6.1.1)
• Manually rotate the left knob of the battery case.
• Turn the left knob to the unlocking position.
• Open the left battery buckle.
1
2
To Next Page
