Roborock Q80ULL User Manual

07
Installation
B
Important Information
Press any button to stop the robot during cleaning
or docking.
Dock
Spot Clean/Child Lock
Product Overview
A
A1
Robot (Top View)
A2
Robot (Bottom View)
A3
Robot
• Press to return to dock
Note:
A1-1—Vertical Bumper
A1-2—LiDAR Sensor
A1-3—Wall Sensor
A1-4—Dock Locator
A1-5—Reactive Tech Obstacle Avoidance
Sensor
• Press to Spot clean
• Press and hold for 3 seconds to
turn on/off the child lock
A3-1—Reset Button
A3-2—Air Vent
A3-3—Mop Cloth Mount
A3-4—Bumper
• White: Battery level ≥ 20%
• Red: Battery level < 20%
• Breathing: Charging or starting up
• Flashing red: Error
Power Indicator
Power/Clean
• Press and hold to turn the robot
on or off
• Press to start cleaning
A2-1—Cliff Sensors
A2-2—Omnidirectional Wheel
A2-3—Charging Contacts
A2-4—Side Brush
A2-5—Main Brushes
A2-6—Main Brush Cover
A2-7—Main Wheels
A6
Power Cable
• Flashing blue slowly: Waiting for
connection
• Flashing blue quickly: Connecting
• Steady blue for five seconds: WiFi
connected
—WiFi Indicator Light
A4
Dustbin and Water Tank
Combo Unit
A4-1—Latch
A4-2—Stopper
A4-3—Water Filter
A4-4—Washable Filter
A5
Charging Dock
A5-1—Power Indicator
A5-2—Dock Location Beacon
A5-3—Charging Contacts
A5-4—Power Socket
A5-5—Electrode Brushes
A7
Mop Cloth Mount
A7-1—Mop Cloth Attachment Slot
A7-2—Mop Cloth Mount Latches
A8
Mop Cloth
A8-1—Hook and Loop Pads
A9
Moisture-Proof Mat
