09
•
Press to return to dock/start emptying
•
Press and hold to start spot cleaning/
mop washing
—Dock
•
Press and hold to turn the robot
on or off
•
Press to start cleaning
—Power/Clean
•
White: Battery level
≥
15%
•
Red: Battery level < 15%
•
Breathing: Charging or starting up
•
Flashing red: Error
—Power Indicator Light
Press any button to stop the robot during cleaning
or docking.
Note:
A1-1—Dock Locator
A1-2—Reactive Tech Obstacle Avoidance
Sensor
A2-1—Wall Sensor
A2-2—Omnidirectional Wheel
A2-3—Carpet Sensor
A2-4—Side Brush
A2-5—Main Wheel
A2-6—Main Brush
A2-7—Main Brush Cover Latches
A2-8—Mop Cloths
A2-9—Cliff Sensors
A3-4—Reset Button
A3-5—Dustbin
A3-6—Charging Contacts
A3-7—Communication Sensor
A3-8—Air Outlet
A3-9—Positioning Button
A3-10—Self-Filling Port
A3-11—Automatic Lift and Rotate Mop
Modules
A3-12—Suction Inlet
A3-13—Bumper
A3-1—Vertical Bumper
A3-2—LiDAR Sensor
A3-3—WiFi Indicator Light
•
Off: WiFi disabled/Charging
•
Flashing slowly: Waiting for connection
•
Flashing quickly: Connecting
•
Steady: WiFi connected
A4-1—Hook and Loop Pads
A4-2—Mop Axle
Secure the mop cloths in place.Note:
Product Overview
A
A1
Robot (Top View)
A2
Robot (Bottom View)
A3
Robot (Top Cover Open)
A4
Mop Cloth Mount
A5
Mop Cloth
A6-1—Dustbin Latch
A6-2—Air Inlet
A6-3—Washable Filter
A6-4—Suction Inlet
A6
Dustbin
A7
Dock Base
A8
Power Cord
A9
Disposable Dust Bag
A10-1—Water Tank Handle
A10-2—Water Tank Latch
A10-3—Dirty Water Tank
A10-4—Dust Container Cover
A10-5—Charging Contacts
A10-6—Robot Refill Port
A10-7—Suction Inlet
A10-8—Clean Water Tank
A10-9—Status Indicator Light
•
Breathing: Emptying/Mop washing
•
Red: Dock error
•
Off: Powered off/Charging
A10-10—Water Outlet
A10-11—Air Outlets
A10-12—Dock Base
A10-13—Filter
A10-14—Dust Bag Slot
A10-15—Dock Location Beacon
A10-16—Clean Water Dispensers
A10
Dock
