Robotics V3 - Step 12: Upper Chassis Installation

33
Mount the upper chassis to the four metal spacers as show below using the
¼ inch screws. Also install the Arduino Sensor Shield as seen below.
Note:- Pull the servo and feeler wires thru the holes as shown below for
each side
Parts
- Upper chassis
- (4) 1/4” screws
- Arduino board
- Star screwdriver
Step 10: Install Upper Chassis on Metal Spacers
