RoboToolz RT-7690-2 - System Components; Base Unit Components; RF Remote Control;Laser Detector Components

RT-7690-2 User Guide
3
RT-7690-2 Components
The following illustrations show the main components of the RT-7960-2 laser system base unit
and RF remote control/laser detector.
Base Unit (front)
Retractable
Antenna
Tripod Mount
Level Laser
Aperture Helmet
Plumb Laser
Aperture Helmet
Plumb Laser
Aperture
Level Laser
Aperture
Handle
Battery
Compartment
Base Unit (back)
Power Switch/
Pendulum Lock
Laser
Controls
Base Unit LED
AC/DC Port
Retractable
Antenna
Laser
Controls
LCD
Display
Detector
Panel
RF Remote Control/
Laser Detector
X
Y
X
Y
Calibration
Port
CA
