Robustel R3000-Q3PA User Manual

Robustel GoRugged R3000 Quad User Guide
RT_UG_R3000 Quad_v.2.0.1 15.11.2016 40 / 111
Confidential
DHCP Server
Item
Description
Default
DHCP Server for Relay
Enter the DHCP Relay server IP address.
Null
Debug Enable
Enable this function; it will output the DHCP information to syslog.
OFF
Multiple IP
Click to edit the Multiple IP of the LAN interface. Click to delete the Multiple IP of the LAN interface.
Click to add a multiple IP to the LAN interface.
Multiple IP
Item
Description
Default
Interface
Select lan0~lan3.
When eth0 used As WAN, lan3 is unavailable.
And lan1~lan3 available only if it was selected by at least one
Ethernet port in Ethernet->Port Setting section.
lan0
IP Address
Set the multiple IP Address of the LAN interface.
Null
Netmask
Set the multiple Netmask of the LAN interface.
Null
