Technical Parameters
Model SC-2420 SC-2440 SC-2460
Rated Voltage 12V / 24V Automatic voltage detection
Max Solar current 20A 40A 60A
Max Load current 20A 40A 60A
Full charge cut out Voltage 13.7V/27.4V Default (user settable)
Low voltage cut out voltage 10.5V/21V Default (user settable)
Temperature compensation -3mv//cell
No load loss
≤20mA (when configured in 12V system)
≤30mA (when configured in 24V system)
Max wire diameter 6 mm
2
8 mm
2
Ambient temperature -25 to +55
Solar panel input voltage
(working)
20V (12V System)
40V (24V system)
*note: panel, battery and load nominal voltages should always be the
same
Solar panel Voc Max
50V
Model SC-4840 SC-4860
Rated Voltage 48V
Max Solar current 40A 60A
Max Load current 40A 60A
Full charge cut out Voltage 54.8V Default (user settable)
Low voltage cut out voltage 42V Default (user settable)
Temperature compensation -3mv//cell
No load loss ≤40mA
Max wire diameter 8 mm
2
8 mm
2
Ambient temperature -25 to +55
Solar panel input voltage
(working)
60V
Solar panel Voc Max
100V

Roc-Solid SC-2420 Specifications

General

Brand	Roc-Solid
Model	SC-2420
Category	Control Unit
Language	English
