Rocal Drop - 1. Specifications; 1.1 Technical Specifications; 1.2 Breakdown of Delivery Components; 1.3 Equipment Measurements Diagram

8
1.1 Technical specifications
Parameter
Drop
Mini Drop
Minimum - Maximum draught 11-13 Pa 11-13 Pa
Fuel consumption 2,64 kg/h 2,14 kg/h
Smoke mass flow rate 9,5 g/s 8,8 g/s
Performance
85,03 %
85,1 %
Nominal output 9,9 kW 8,1 kW
Power range 6,5 – 11,5 kW 3,8 – 9,5 kW
Average CO concentration at 13% of O
2
0,093 % 0,072 %
NOx concentration at 13% of O
2
113 mg/Nm
3
92 mg/Nm
3
OGC concentration at 13% of O
2
67 mg/Nm
3
63 mg/Nm
3
Particle concentration at 13% of O
2
9,1 mg/Nm
3
29.2 mg/Nm
3
Medium draft (trial) 10,9 Pa 10,5 Pa
Net weight 148 kg 113 kg
Maximum authorized load (fuel) 3,5 kg 3 kg
Reload height 200 mm 200 mm
Logs length 330 mm 250 mm
Minimum flue height 4000 mm 4000 mm
Flue duct 176 x 166 (Ø 180) mm 152 x 144 (Ø 150) mm
Ø Air inlet 120 mm 100 mm
Front safety distance 1000 mm 1000 mm
Side safety distance 300 mm 400 mm
Back safety distance 500 mm 300 mm
Base safety distance 300 mm 300 mm
Average temperature of smoke 178,2 º C 167,1 º C
Type of combustion INTERMITTENT
Flue liner NOT SHARED
Fuel NATURAL WOOD
Humidity fuel logs 12-20% - two years under cover
Certification year 2019
2020
Certificate No.:
1880
-
CPR
-
067
-
19
1880-CPR-022-20
1.2 Breakdown of delivery components
( Make sure you have all the components described below in relation to the picture on section II of the ANNEXED document)
1.
Fireplace’s body.
2.
Direct flue pipe.
3.
Ceiling crest.
4.
Aluminium ring to connect, exterior air inlet cover and metal clamp.
5.
Heat-resistant spray paint for touch-ups.
6.
Bag with: 4x anchors and 4x screws.
7.
Tool to install flue pipe.
8. Documentation bag: output declaration, energy label, guarantee, technical sheet, and installation and operating
characteristics manual.
9.
Heat-resistant glove.
10.
Tool for handling registers.
11.
Cleaning cloth.
12.
Ceramic adhesive rope.
13.
Bag with: 8x screws
14.
Bag with: 6x metal anchors
15.
A (Mini Drop) Upper baffle to limit the draught. B (Drop) Upper baffle to limit the draught.
1.3 Diagram of the equipment's measurements
See the ANNEXED document, section I
ALL LOCAL STANDARDS, INCLUDING NATIONAL AND EUROPEAN REGULATIONS MUST BE COMPLIED WITH UPON
INSTALLATION OF THE EQUIPMENT.
THE INSTALLATION MUST BE PERFORMED BY A PROFESSIONAL. FAILURE TO COMPLY WITH THIS CLAUSE SHALL
EXONERATE THE MANUFACTURER FROM ANY RESPONSIBILITY.
2.1 Ground. In case it is installed with the optional foot support, make sure the ground where the appliance will be placed is able to
support the weight of the device. If not, you will need a load spreading plate for the equitable distribution of the equipment's weight.
In case of doubt, please consult a specialist.
