rock space AC1200 - Page 2

POWER
This indicator lights red when the router powered on, otherwise it is off.
WPS
This indicator keeps lighting after pairing successful.
WLAN
This indicator light when there are wireless devices connected and transmitting data to
the router.
WAN
When the WAN port is connected successfully the indicator light.
While transmitting or receiving data through the WAN port the indicator blinks.
1.3.2 Rear Panel
The figure below shows the rear panel of router RSD0611.
Power
The Power socket is where you will connect the power adapter.
WAN
This port is where you will connect with the cable to access Internet.
1/2/3
LAN
This port connects the router to local PC.
