Status indicators
LED indicators LED Description
Backup button Solid The hard drive is turned on.
Flashing Data is being transmitted between your
computer and the hard drive.
Off The hard drive is turned off.
Card reader Solid A memory card is in the reader.
Flashing Data is being transmitted between your
computer and the card reader.
Off The memory card reader slot is empty.
POWER ON/OFF
button
eSATA port
USB port
DC power jack
